The DFAC EV1 is an electric light-duty truck with a 1715 cab, 2-seater layout, right-hand drive, and 4×2 driving type. Its gross vehicle weight is 3000 kg, curb weight is 1440 kg, and load mass is 1560 kg. It measures 4995 × 1770 × 2070 mm, with a cargo deck of 3050 × 1680 × 360 mm, wheelbase of 3050 mm, front/rear track of 1560/1450 mm, front/rear overhang of 750/1195 mm, minimum ground clearance of 194 mm, and maximum speed of 90 km/h.
Power comes from a CATL 41.86 kWh battery with AC/DC charging, NEDC range of 300 km, 6.6 kW OBC, and GB/T charging socket. The permanent magnet synchronous motor produces 35/70 kW rated/peak power and 90/230 Nm rated/peak torque, enabling gradeability of at least 25% and 0–50 km/h acceleration in 6.8 seconds. It uses independent front suspension, non-independent rear suspension with vertical leaf spring, and electric power-assist steering.
The EV1 rides on 195R14C 8PR tubeless tyres with a 4+1 configuration. Braking is hydraulic with front discs, rear drums, and a mechanical rear-wheel parking brake. Features include radio + USB, electric windows, and air conditioning.
Seats
3
Top Speed
300KM|
Item |
Specification |
|
Model |
EV1 |
|
Cab |
1715 2-Seater |
|
Driving Type |
4×2 |
|
Cab-by the Number |
2 |
|
Steering Wheel Position |
RHD |
|
Gross Vehicle Weight (G.V.W.) |
3000 kg |
|
Curb Weight |
1440 kg |
|
Load Mass |
1560 kg |
|
Dimension (mm) |
4995 x 1770 x 2070 |
|
Cargo Deck (mm) |
3050 x 1680 x 360 |
|
Wheelbase (mm) |
3050 |
|
Front / Rear Track (mm) |
1560/1450 |
|
Overhang F/R (mm) |
750/1195 |
|
Minimum Ground Clearance (mm) |
194 |
|
Maximum Speed (km/h) |
90 |
| Item | Specification |
|---|---|
| Capacity (kWh) | CATL 41.86 |
| Charge Mode | AC/DC |
| Range NEDC (km) | 300 |
| Item | Specification |
|---|---|
| Power Rate/Peak (kW) | 35/70 |
| Torque Rate/Peak (Nm) | 90/230 |
| Motor Type | Permanent Magnet Synchronous Motor |
| Item | Specification |
|---|---|
| Gradeability | ≥25% |
| Acceleration (0-50 km/h) | 6.8 s |
| Item | Specification |
|---|---|
| OBC Charge (kW) | 6.6 |
| Charging Socket | GB/T |
| Item | Specification |
|---|---|
| Front Axle Type | Independent Suspension |
| Rear Suspension | Non-Independent Suspension Vertical Leaf Spring |
| Steering Power Form | Electric Power Assist |
| Item | Specification |
|---|---|
| Tyre | 195R14C 8PR |
| Number of Tyres | 4+1 |
| Tubeless | Yes |
| Item | Specification |
|---|---|
| Brake | Hydraulic Brake |
| Front Brake | Disc |
| Rear Brake | Drum |
| Parking Brake | Brake Rear Wheel (Mechanical) |
| Item | Specification |
|---|---|
| Radio + USB | Yes |
| Electric Windows | Yes |
| Air Condition | Yes |
